| Jiangsu Tengfa Construction Machinery Co., Ltd | ||||||
| Mast Section Dimension | Suitable Model |
Head Type | Jib Length M |
Max Load TON |
Independent Height M |
Max Height |
| 0.65*0.65*1.508 | SC200/200 | Construction Lifter | 2*2000 | 60 | 150 | |
| 1.4*1.4*2.0 | QTP50(5010) | Flat Top | 50 | 4 | 31.5 | 120 |
| QTZ40(4808) | Topkit | 48 | 4 | 31.5 | 120 | |
| QTZ50(5008) | Topkit | 50 | 4 | 31.5 | 120 | |
| QTZ50(5010) | Topkit | 50 | 4 | 31.5 | 120 | |
| 1.6*1.6*2.8 | QTP63(5013) | Flat Top | 50 | 5 | 35 | 140 |
| QTP63(5210) | Flat Top | 52 | 5 | 35 | 140 | |
| QTP63(5610) | Flat Top | 56 | 6 | 35 | 140 | |
| QTP80(5810) | Flat Top | 58 | 6 | 40.5 | 141 | |
| QTZ63(5013) | Topkit | 50 | 5 | 35 | 140 | |
| QTZ80(5810) | Topkit | 58 | 6 | 40.5 | 141 | |
| QTZ80(6010) | Topkit | 60 | 6 | 40.5 | 141 | |
| QTZ100(6013) | Topkit | 60 | 6 | 40.5 | 141 | |
| 1.6*1.6*2.8 1.8*1.8*2.8 |
QTP100(6013) | Flat Top | 60 | 6-8 | 41 | 181 |
| 1.8*1.8*2.8 | QTD125 | Topkit | 45 | 8 | 30 | 46 |
| QTD160 | Topkit | 45 | 10 | 30 | 46 | |
| QTPS125(6016) | Flat Top | 60 | 8-10 | 46.8 | 181 | |
| QTP160(6022) | Flat Top | 60 | 10 | 46.8 | 198 | |
| QTZ125(6015) | Topkit | 60 | 10 | 44 | 160 | |
| QTZ160(6020) | Topkit | 60 | 10 | 46.8 | 185 | |
| QTZ160(6516) | Topkit | 65 | 10 | 45 | 185 | |
| 2.0*2.0*2.8 | QTP200(6030) | Flat Top | 60 | 10 | 46.8 | 198 |
| QTZ200(6030) | Topkit | 60 | 10 | 49.6 | 198 | |
| 2.0*2.0*3.0 | QTP160(7015) | Flat Top | 70 | 10-12 | 60 | 195 |
| QTP315(7033) | Flat Top | 70 | 12-16 | 48.7 | 186.7 | |
| QTZ160(7015) | Topkit | 70 | 10-12 | 60 | 195 | |
| QTZ200(7020) | Topkit | 70 | 12 | 60 | 210 | |
| QTZ315(7033) | Topkit | 70 | 12-16 | 48.7 | 186.7 | |
| QTZ315(7040) | Topkit | 70 | 16 | 48.7 | 186.7 | |
